Copper Nickel 90/10 Pipe Fittings – Manufacturer, Supplier & Exporter in Mumbai, India

Copper Nickel 90/10 Pipe Fittings – Manufacturer, Supplier & Exporter in Mumbai, India

Virami Steel Hub is a leading manufacturer, supplier, stockist, and exporter of high-quality Copper Nickel 90/10 Pipe Fittings in Mumbai, India. We offer a wide range of premium Cu-Ni alloy pipe fittings designed for excellent corrosion resistance, durability, and cost-effective performance in marine and industrial applications.

Our Copper Nickel 90/10 pipe fittings are manufactured using superior-grade raw materials and advanced production processes to ensure precise dimensions, reliable mechanical strength, and long service life. These fittings are widely used in industries where moderate strength and excellent resistance to seawater corrosion are required.

With a strong distribution network, we supply across India and export to the USA, Europe, the Middle East, Africa, and Southeast Asia, ensuring consistent quality and timely delivery.

Stainless Steel 316 Round Bars

What are Copper Nickel 90/10 Pipe Fittings?

Copper Nickel 90/10 Pipe Fittings are piping components used in industrial piping systems to:

  • Connect pipelines
  • Change flow direction
  • Branch piping systems
  • Control fluid transport

These fittings are made from Copper Nickel 90/10 (Cu-Ni 90/10) alloy, which consists of approximately 90% copper and 10% nickel, offering excellent corrosion resistance, especially in seawater environments.


Chemical Composition (Typical)

  • Copper (Cu): 88.6 - 90.7%
  • Nickel (Ni): 9 - 11%
  • Iron (Fe): 1.0 - 1.8%
  • Manganese (Mn): 0.5 - 1.0%
  • Carbon (C): ≤ 0.05%
  • Lead (Pb): ≤ 0.02%

Key Features of Copper Nickel 90/10 Pipe Fittings

  • Excellent resistance to seawater and marine corrosion
  • Good resistance to biofouling
  • High resistance to corrosion in brackish water
  • Good mechanical strength
  • Excellent thermal conductivity
  • Cost-effective compared to 70/30 alloy
  • Good fabrication and weldability
  • Reliable performance in moderate flow conditions

Mechanical Properties

  • Tensile Strength: ~275 - 380 MPa
  • Yield Strength: ≥ 105 MPa
  • Elongation: ≥ 30%
  • Hardness: ~80 - 100 HB
  • Density: 8.90 g/cm³

Physical Propertiess

  • Melting Range: 1090 – 1145°C
  • Modulus of Elasticity: ~140 GPa
  • Thermal Conductivity: ~40 W/m·K
  • Electrical Resistivity: ~0.20 µΩ·m
  • Coefficient of Thermal Expansion: ~17 µm/m°C

Corrosion Resistance

Copper Nickel 90/10 Pipe Fittings provide excellent resistance to:

  • Seawater and marine atmospheres
  • Biofouling and marine growth
  • Brackish water corrosion
  • Saltwater environments
  • Mild industrial chemicals

These properties make them highly suitable for marine and cooling water applications.


Heat Treatment

Copper Nickel 90/10 is typically supplied in:

  • Annealed condition

This improves ductility and ease of fabrication.


Weldability

Copper Nickel 90/10 offers good weldability:

  • TIG (GTAW)
  • MIG (GMAW)
  • SMAW

Recommendations:

  • Use Cu-Ni compatible filler materials
  • Maintain clean welding surfaces
  • Control heat input

Machinability

Copper Nickel 90/10 has good machinability:

  • Use standard cutting tools
  • Maintain proper cutting speeds
  • Use adequate lubrication

Standards & Specifications

  • ASTM B366
  • ASME SB366
  • ANSI B16.9
  • ASTM B466
  • ASTM B467

Available Types of Copper Nickel 90/10 Pipe Fittings

  • Elbows (45° and 90°)
  • Tees (Equal and Reducing)
  • Reducers (Concentric and Eccentric)
  • Pipe Caps
  • Stub Ends
  • Cross Fittings
  • Couplings

Sizes & Specifications

  • Size Range: ½ inch to 48 inches
  • Thickness: SCH 10, SCH 20, SCH 40, SCH 80, SCH 160
  • Types: Seamless and Welded

Surface Finish:

  • Pickled
  • Polished
  • Matte

(Custom sizes available as per project requirements)


Applications of Copper Nickel 90/10 Pipe Fittings

Marine Industry

  • Seawater piping systems
  • Shipbuilding

Power Generation

  • Cooling water systems
  • Condensers

Oil & Gas Industry

  • Offshore piping systems
  • Low-pressure applications

Desalination Plants

  • Saltwater handling

HVAC & Heat Exchangers

  • Cooling and heat transfer systems

Quality Testing & Inspection

All fittings undergo strict quality checks:

  • Chemical composition testing
  • Mechanical testing
  • Dimensional inspection
  • Surface quality inspection
  • PMI testing

We provide Mill Test Certificates (MTC) and third-party inspection services.

Packaging & Delivery

  • Export-grade wooden boxes or pallets
  • Protective wrapping
  • Proper labeling and traceability
  • Secure global shipping

Why Choose Virami Steel Hub?

  • Trusted Cu-Ni pipe fittings manufacturer in Mumbai
  • Large ready stock availability
  • Competitive pricing
  • Custom manufacturing solutions
  • Compliance with international standards
  • Strong global export network
  • Reliable customer support

Conclusion

Copper Nickel 90/10 Pipe Fittings are widely used in industries requiring cost-effective corrosion resistance, especially in marine and cooling water applications. Their durability, ease of fabrication, and resistance to seawater make them a preferred choice for various industrial uses.

Virami Steel Hub supplies high-quality Copper Nickel 90/10 pipe fittings manufactured according to international standards, ensuring reliable performance and long service life.
